Teltonika FMB125 GPS Tracker
The Teltonika FMB125 is an advanced GPS tracker designed for various vehicle tracking applications, including fleet management and assets tracking.
Key Features:
- Compact design with internal backup battery
- Supports both 2G and 3G networks for enhanced connectivity
- RS232 and RS485 interfaces for connecting additional equipment
- Real-time GPS tracking and data transmission
- Multiple inputs and outputs for versatile integration
Use Cases:
- Fleet management and vehicle tracking
- Heavy machinery tracking
- Assets tracking for businesses
- Vehicle rental and leasing services
Advantages:
- Reliable performance with dual connectivity (2G/3G)
- Supports a wide range of sensors and accessories
- Efficient fleet management with real-time data
- Cost-effective solution with robust features
- 24/7 customer support from QTLoads
Teltonika FMB125 GPS Tracker
An advanced GPS tracker with dual connectivity (2G/3G) for fleet and assets management.
Detailed Description
The Teltonika FMB125 GPS Tracker provides advanced tracking capabilities for fleet and assets management, offering reliable performance and versatile connectivity options.
Teltonika FMB125: Compact GNSS Tracker for Smart Fleet Solutions The Teltonika FMB125 is a versatile GNSS tracking device designed for efficient fleet management and assets tracking. Featuring advanced GPS technology and a compact design, the FMB125 is suitable for a variety of applications including logistics, transportation, and vehicle security. Its internal antennas enable discreet installations, making it ideal for covert tracking operations. With extensive I/O capabilities, the device can connect to additional sensors and peripherals, enhancing its functionality for diverse industries. The FMB125 provides real-time monitoring, ensuring effective management of fleet operations and improved operational efficiency.
Specifications
| Features | Specification |
|---|---|
| Technology | GSM/GPRS/GNSS/BLUETOOTH |
| GNSS | GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS, DGPS, AGPS |
| Receiver | 33 channel |
| Tracking sensitivity | -165 dBM |
| Position Accuracy | < 2.5 m CEP |
| Hot start | < 1 s |
| Warm start | < 25 s |
| Cold start | < 35 s |
| GSM Technology | GSM |
| 2G bands | Quad-band 850 / 900 / 1800 / 1900 MHz |
| Data transfer | GPRS Multi-Slot Class 12 (up to 240 kbps), GPRS Mobile Station Class B |
| Data support | SMS (text/data) |
| Input voltage range | 10–30 V DC with overvoltage and reverse polarity protection |
| Internal Back-up battery | 170 mAh Li-Ion battery, 3.7 V (0.63 Wh) |
| Power consumption | At 12V < 6 mA (Ultra Deep Sleep) At 12V < 6.5 mA (Deep Sleep) At 12V < 7 mA (Online Sleep) At 12V < 12 mA (GPS Sleep) At 12V < 38 mA (nominal) |
| Specification | 4.0 + LE |
| Supported peripherals | Temperature and Humidity sensor, Headset, OBDII dongle, Inateck Barcode Scanner, Universal BLE sensors support |
| Digital Inputs | 1 |
| Digital Outputs | 1 |
| Analog Inputs | 1 |
| CAN Adapter Inputs | 1 |
| 1-Wire | 1 |
| RS232 | 1 |
| RS485 | 1 |
| GNSS antenna | External (SMA connector) / internal (optional) |
| Cellular antenna | Internal GSM High Gain |
| USB | 2.0 Micro-USB |
| LED indication | 2 status LED lights |
| SIM | Dual SIM |
| Memory | 128MB internal flash memory |
| Dimensions | 65 x 56.6 x 18.9 mm (L x W x H) |
| Weight | 52 g |
| Operating temperature (without battery) | -40 °C to +85 °C |
| Storage temperature (without battery) | -40 °C to +85 °C |
| Operating humidity | 5% to 95% non-condensing |
| Ingress Protection Rating | IP41 |
| Battery charge temperature | 0 °C to +45 °C |
| Battery discharge temperature | -20 °C to +60 °C |
| Battery storage temperature | -20 °C to +45 °C for 1 month -20 °C to +35 °C for 6 months |
| Sensors | Accelerometer |
| Scenarios | Green Driving, Over Speeding detection, Jamming detection, GNSS Fuel Counter, DOUT Control Via Call, Excessive Idling detection, Immobilizer, iButton Read Notification, Unplug detection, Towing detection, Crash detection, Auto Geofence, Manual Geofence, Trip |
| Sleep modes | GPS Sleep, Online Deep Sleep, Deep Sleep, Ultra Deep Sleep |
| Configuration and firmware update | FOTA WEB, FOTA, Teltonika Configurator (USB, Bluetooth), FMBT mobile application (Configuration) |
| SMS | Configuration, Events, DOUT control, Debug |
| GPRS commands | Configuration, DOUT control, Debug |
| Time Synchronization | GNSS, NITZ, NTP |
| Fuel monitoring | LLS (Analog), LV-CAN200, ALL-CAN300, CAN-CONTROL, OBDII dongle |
| Ignition detection | Digital Input 1, Accelerometer, External Power Voltage, Engine RPM (CAN Adapters, OBDII dongle) |
| RS232 Modes | Log Mode, NMEA, LLS, LCD, RFIH HID/MF7, Garmin FMI, TCP ASCII/Binary |
| RS485 Modes | Log Mode, NMEA, LLS, TCP ASCII/Binary |
| Regulatory | CE/RED, EAC, E-Mark, RoHS, REACH, SIRIM QAS |
Features
Extended product usage scenarios
Significantly lower roaming costs
Temperature Monitoring and Accurate fuel usage control
Product Comparison
| Model | Input Voltage | Weight | Battery | Operating Temperature | Water Resistance |
|---|---|---|---|---|---|
| Teltonika 125 | 10–30 V DC with overvoltage and reverse polarity protection | 52g | 170 mAh Li-Ion battery, 3.7 V (0.63 Wh) | -40 °C to +85 °C | IP41 |
| Teltonika TFT100 | 6–30 V DC with overvoltage protection | 169g | 1800 mAh Li-Ion battery, 3.7V (6.66Wh) | -20 °C to +75 °C | IP67 |
| Teltonika FMB920 | 6–30 V DC with overvoltage protection | 54g | 170 mAh Li-Ion battery (0.63 Wh) | -40°C to +85°C | IP54 |
| Teltonika FMB120 | 10–30 V DC with overvoltage and reverse polarity protection | 55g | 170 mAh Li-Ion battery, 3.7 V (0.63 Wh) | -40 °C to +85 °C | IP41 |
| Teltonika FMB209 | 10–30 V DC with overvoltage and reverse polarity protection | 205g | 800 mAh Li-Ion battery (0.49 Wh) | -40 °C to +85 °C | IP67 |
